Printers for Plastic & Glass Bottles & Containers
Plastic Bottle Printers
Graphics International Group (GIG) offers a wide range of models capable of printing 1 to 12 colors on plastic bottles, jars, caps, and jugs of various shapes, complete with automatic feeding and discharge systems for seamless operation.
We are continuously advancing our technology to enhance ease of use while enabling full 360-degree printing across diverse container designs.
SERVO - UV TURNTABLE PRINTERS - BOTTLES & JARS
BOTTLES & JARS
Servo Turntable Printer
for Bottles & Jars
Up to 6 Color Printing
Speed Up to 60pcs /min
Diameter at 360degree
Degree 13 -100mm
Container Height 20-320 mm
Max Printing Length300mmMax Printing Height200mm
PLASTIC BOTTLES
Servo Modular HA Printer
BOTTLES & JARS FLAT
Servo Turntable UV Printer
BABY BOTTLES
Modular Screen HA Printer
Specification: IR8640
Up to 6 Colors
16 Station
Printing Speed Up to 40pcs/ min
Diameter of 360° 13-65 mm
Bottle Height 20-220 mm
Printing Length 200mm
Printing Height 120m
GIG SM666
GIG-SM 666: Automatic UV Screen Printer for printing up to 8 colors inline of plastic bottles (cylindrical).
Our Services
We offer a wide range of services including prototyping, product design, and manufacturing. Our state-of-the-art facility and skilled team allow us to provide our clients with custom solutions that meet their unique needs.
GIG 688
This servo-driven automatic printer is suitable for plastic containers including bottles, jars and hard tubes. It will print round, oval, triangular, square and pentagon shapes. Multi-color, 360 degree, UV printing can be achieved.
The machine has digitally controlled, servo-driven screen printing and UV curing stations. A maximum of 8 colors can be printed. Each printing station can be individually adjusted.
SPECIFICATIONS
Output: up to 85 parts per minute
Printing diameter at 360°: 19-154(3/4”–6”)
Bottle height: 51–305mm(2”–12”)
Max. printing length: 305mm (12”)
Max. printing height: 254mm (10”)
Our Capabilities
We offer a wide range of services including CNC machining, injection molding, and sheet metal fabrication. Our team has experience working with a variety of materials including plastics, metals, and composites. We also offer design and engineering services to help our clients bring their ideas to life.
GIG SM 888
The Round Bottle Printing Machine - Also Great for Hand Sanitizer & Disinfectant Bottle Printing
GIG SM888 can be integrated with hot stamping, labeling and/or inspection modules created a multi-functional printing line.
The machine can be fed via automatic unscrambler, manually fed, and also has the option to integrate discharge to a bagging system to save operator time.
Output up to 100 parts per minute
Diameter of cylinder: 19-120 mm (3/4” – 4 ¾”)
Radius of elliptical container: 25-254 mm (1” - 10”)
Length of container: 25-305 mm (1” – 12”)
Max printing length: 305 mm (12”)
Max printing width: 254 mm (10”).
Our Services
We offer a wide range of services including prototyping, product design, and manufacturing. Our state-of-the-art facility and skilled team allow us to provide our clients with custom solutions that meet their unique needs.
GIG SRS310 CNC ROTARY PRINTER
Fully automatic, rotary screen printer for various shapes.
The GIG-SRS310 range of fully automatic screen printers are driven by CNC servo motor and can print 360 degrees on plastic, glass, metal bottles, jars, caps of various shapes. Rounds, ovals, triangular, square and pentagon shapes can be accommodated.
The bottle is rotated through workstations in one fixture as follows: feeding, registration, surface pre-treatment, multi-color printing, UV curing and discharging. The print registration is excellent, the distance from print to bottom of the bottle is small, and containers with delicate surfaces can be accommodated.
Like many of our machines, curing can partially or fully be done using LED curing systems to save energy and minimize heat/bottle damage/ink shrinkage.
It is possible to replace a screen printing/curing station with hot stamping and have a machine with multiple decoration functions.
Additionally, a vision inspection station can be added, allowing unacceptable product to be discharged and separated for good product.
The GIG-SRS310 and its range of machines come equipped with remote management functions that connect customers to the GIG factory to troubleshoot the machine.
